CS3164GS

Name: CS3164GS
Brand: 深圳市西迪特科技股份有限公司

CS3084XX/CS3164XX/CS3244XX 是一款全千兆二层网管型以太网交换机。

它提供 8/16/24 个千兆 PoE 端口和 4 个 SFP 端口，能够满足高性价比千兆接入网络的需求。

它采用存储转发和动态内存分配技术，确保每个端口都能实现线性转发。

该产品具备丰富的二层特性，例如 VLAN、QoS、STP/RSTP/MSTP、LACP、ACL 等，

广泛应用于企业网和园区网的接入。它为用户提供高性能、易管理、易扩展、低成本的千兆到桌面解决方案。

Functional Feature

Comply to IEEE 802.3 、 IEEE 802.3u 、 IEEE 802.3ab 、 IEEE 802.3z 、 IEEE802.1Q 、 IEEE802.1ad 、 IEEE802.3ad 、 IEEE802.1d/ 1w/ 1s.
8&16&24* 10/ 100/ 1000M RJ45 adaptive ports ，support Auto MDI/ MDIX.
4*1000M SFP ports.
Support IEEE802.3af/at.
Support abundant L2 features such as VLAN, LACP,QoS,ACL.
Support AAA authentication, support Radius,TACACS+ authentication.
Support IGMP V1/V2/V3 Snooping.
Support DHCP V4/V6 Snooping.
Support CLI/SNMP/WEB UI/CMS Management.
Embeded power,1U metal shell,standard rack structure.

Models	CS3084GS	CS3164GS	CS3244GS
Physical Interface	810/ 100/ 1000M BASE-T 2GE SFP + 2*GE/2.5GE SFP	16* 10/ 100/ 1000M BASE-T 4*GE SFP	24* 10/ 100/ 1000M BASE-T 4*GE SFP
Management port	1* RJ45 Console Port	1* RJ45 Console Port	1* RJ45 Console Port
Fixed power supply	one	one	one
Power Consumption	≤15W	≤24W	≤28W
Fixed fan	NA	one	one
	Each port has 1 Link/Ack indicator Each device has 1 Power indicator Each device has 1 System indicator
Led light
Dimension (W×D ×H)mm	360* 180*44	440* 181*44	440* 181*44
Models	CS3084GSP	CS3164GSP	CS3244GSP
Physical Interface	810/ 100/ 1000M BASE-T 2GE SFP + 2*GE/2.5GE SFP	16* 10/ 100/ 1000M BASE-T 4*GE SFP	24* 10/ 100/ 1000M BASE-T 4*GE SFP
Management port	1* RJ45 Console Port	1* RJ45 Console Port	1* RJ45 Console Port
Fixed power supply	one	one	one
Max PoE Power Consumption	140W	300W	390W
POE standard	IEEE 802.af/at	IEEE 802.af/at	IEEE 802.af/at
Fixed fan	one	one	one
Dimension (W×D ×H)mm	380* 180*44	440263.7 44	440263.7 44
Led light	Each port has 1 Link/Ack indicator Each port has 1 PoE indicator
Led light	Each device has 1 Power indicator Each device has 1 System indicator
Working Voltage	AC 100-240V/50-60Hz
Working temperature	0 - to 50℃
Storage temperature	-40 - 70℃
Ambient humidity	10% ~90%RH,non-condensing
Storage humidity	5% ~90%RH,non-condensing
Anti-Lightning	Port:6KV,Power:4KV
Anti-Static	8KV
