FD714TS3-R850S
4GE+2WIFI6(AX3000)+CATV XGSPON ONU

Name: FD714TS3-R850S
Brand: 深圳市西迪特科技股份有限公司

FD714TS3-R850s is WiFi6 XGSPON Gateway ONT,it support 802.11a/b/g/n/ac/ax standards over 2.4GHz and 5GHz,max speed can up to 3000Mpbs.

FD714TS3-R850s have a high reliability and provide quality of service guarantee, easy management, flexible expansion and networking. It fully meets the ITU-T technical standards and have good compatibility with third party OLT.

 下载  询价

Technical Specifications

Mechanics
Dimensions	210mm(L)135mm(W)45mm(H)
Weight	About 300g

Hardware
User Port (LAN)		RJ-45 connector
		4* 10/ 100/ 1000Mbps adaptive Ethernet port
		Full/half duplex
		Auto MDI/ MDI-X
Indicators		PWR / PON / LOS / LAN1-4 / INT / WIFI / CATV
PON Port	PON Mode	XGSPON：FSAN G.9807.1 standard
	PON Rate	XGSPON：10Gbps/10Gbps downstream/upstream
	Wavelength	Transmit: 1270nm	Receiver: 1577nm
	Receiving sensitivity	XGSPON：-28dBm
	Saturated power	XGSPON：-9dBm
	Average sending	XGSPON：+4～+9dBm

WIFI

IEEE802.11b/g/n/ax(2.4G) IEEE802. 11a/n/ac/ax(5G)

2.4G: 40Mhz bandwidth maximum rate 574Mbps

5G：160Mhz bandwidth maximum rate 2402Mbps

Total wireless rate is 3000Mbps

2.4G EIRP:22dBm / 5 G EIRP:21dBm

CATV（Input /Output port）

Wavelength: 1550nm

Input optical power: -18dBm～0dBm(with AGC)

RF frequency: 47MHz~ 1000MHz

RF output level: 78dBuV (@-12~-2dBm@85MHz) (with AGC)

RF output return loss: >12dB(with AGC)

RF impedance: 75 Ω

Environment
Working temperature	0 to 40ºC
Operating humidity	10% ~ 90% (Non-condensing)

Power
External 12VDC/2A power supply adapter
Power consumption	<18.9W

FD714TS3-R850S 4GE+2WIFI6(AX3000)+CATV XGSPON ONU
