FD514TS3-R850s
4GE+2WIFI6(AX3000) XGSPON ONU

Name: FD514TS3-R850s
Brand: 深圳市西迪特科技股份有限公司

FD514TS3-R850s is WiFi6 XGSPON Gateway ONT,it support 802.11a/b/g/n/ac/ax standards over 2.4GHz and 5GHz,max speed can up to 3000Mpbs.

FD514TS3-R850s have a high reliability and provide quality of service guarantee, easy management, flexible expansion and networking.

Technical Specifications

Hardware
User Port (LAN)		RJ-45 connector
		4* 10/ 100/ 1000Mbps adaptive Ethernet port
		Full/half duplex
		Auto MDI/ MDI-X
Indicators		PWR / PON / LOS / LAN1-4 / INT / WIFI / USB
PON Port	PON Mode	XGSPON：FSAN G.9807.1 standard
	PON Rate	XGSPON：10Gbps/10Gbps downstream/upstream
	Wavelength	Transmit: 1270nm	Receiver: 1577nm
	Receiving sensitivity	XGSPON：-28dBm
	Saturated power	XGSPON：-9dBm
	Average sending	XGSPON：+4～+9dBm

WIFI

IEEE802.11b/g/n/ax(2.4G) IEEE802. 11a/n/ac/ax(5G)

2.4G: 40Mhz bandwidth maximum rate 574Mbps

5G：160Mhz bandwidth maximum rate 2402Mbps

Total wireless rate is 3000Mbps

2.4G EIRP:22dBm / 5 G EIRP:21dBm

Power
External 12VDC/2A power supply adapter
Power consumption	<22.3W
